Utilizzando l'interfaccia LogTag® e il software complementare LogTag® Analyzer, disponibile gratuitamente, il LogTag® può essere facilmente impostato per le condizioni di registrazione, tra cui l'avvio ritardato, l'intervallo di campionamento, il numero di letture, il numero continuo o fisso di letture e la configurazione delle condizioni per attivare l'indicatore ALERT.
Le letture vengono scaricate utilizzando LogTag® Analyzer, che offre funzioni di creazione di grafici, zoom, elenco delle statistiche dei dati e consente di esportare i dati in altre applicazioni come Excel.
Il registratore di temperatura con sonda remota LogTag® misura e memorizza fino a 8000 letture di temperatura in un intervallo di misurazione compreso tra -40 °C e +99 °C.
Nota bene: per la configurazione e la creazione di report è necessaria un'interfaccia.
| Product Model |
TREX-88 |
| Recorder operating temperature range |
-40 °C to +85 °C (-40 °F to +185 °F) |
| Storage Temperature Range |
-10 °C to +55 °C (14 °F to +131 °F) |
| Rated Temperature reading accuracy |
Better than ±0.5 °C (±0.9 °F) for -10 °C to +40 °C (14 °F to +104 °F). Better than ±0.7 °C (±1.3 °F) for -30 °C to -10 °C (-22 °F to 14 °F) & +40 °C to +60 °C (104 °F to 14 0°F). Better than ±0.8 °C (±1.4 °F) for -40 °C to -30 °C (-40 °F to -22 °F) & +60 °C to +80 °C (140 °F to 176 °F). Better than ±1.0 °C (±1.8 °F) for +80 °C to +99 °C (176 °F to 210 °F). Actual performance is typically much better than the rated values. Accuracy figures can be improved by recalibration |
| Rated Temperature Reading Resolution |
Less than 0.1 °C (0.2 °F) for measurements -40 °C to +40 °C (-40 °F to +104 °F). Less than 0.2 °C (0.4 °F) for measurements +40 °C to +80 °C (+104 °F to +176 °F). Less than 0.6 °C (0.5 °F) for measurements +80 °C to +99 °C (+176 °F to +210 °F). LogTag Analyzer® currently displays to one decimal place of °C or °F |
| Sensor Reaction Time |
Typically less than 2 minutes (T90) in moving air (1m/s) for ST100T, ST100H & ST100S types |
| Recording Capacity |
8031 temperature readings. 53 days @ 10min logging, 80 days @ 15min logging |
| Download Time |
Typically less than 5 seconds for full memory (8031 readings), depending on computer or readout device used |
| Environmental |
IP61 |
| Power source |
CR2450 3V LiMnO2 Battery (Fixed) |
| Battery Life |
1 year storage, followed by 2 – 3 years of normal use (based on 15 minute logging, download data monthly) |
| Real Time Clock |
Built-in real time clock. Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day). Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C) |
| Size |
86 mm(H) x 54.5 mm(W) x 8.6 mm(T) |
| Weight |
36 g (without External Probe) |
| Sampling Interval |
Configurable from 30 seconds to 18 hours |
| Logging Start Options |
Push button start or specific date & time. Optional start delay of up to 72 hours |
| Recording Indication |
Flashing ‘OK’ indicator / flashing ‘ALERT’ indicator |
| Case Material |
Polycarbonate |
| External Temperature Sensor Measurement Range |
-40 °C to +99 °C (-40 °F to +210 °F) |
| Standard Remote Sensor Cable Length |
Standard: 1.5 m (4’11”)Extended: 3 m (9’10”) (Recommended maximum) |
| Remote Sensor Cable Type |
PTFE (FDA food contact rated), coaxial |
Tampone glicolico
Il tampone glicolico LogTag® è utilizzato nei casi in cui (...)
Staffa di montaggio a parete WMB-01
Per tutti i modelli LogTag® attuali esclusi gli indicatori e (...)
LTI-HID USB
Culla di interfaccia USB da tavolo LogTag® LTI-HID
Sonde esterne e sonde intelligenti
Tutte le sonde esterne e le smart probe in un (...)
